100kW/215kWh Integrated Cabinet

100kW/215kWh Integrated Cabinet

RAJA New Energy launched 100kW/215kWh industrial and commercial energy storage all-in-one cabinet to achieve energy management and automatic switching within the LAN, to help industrial and commercial users to use the peak-valley difference in the power grid to achieve return on investment, to meet their own internal power demand, to maximize the photovoltaic power generation for self-use, and through the peak-valley price arbitrage.

100kW/215kWh Integrated Cabinet
100kW/215kWh Integrated Cabinet
>
<
Product Features
  • Integrated Design

    Inverter and battery module integrated, capable of direct conversion between AC and DC power.

  • Backup Power

    Provides emergency power supply during grid failures or outages.

  • Intelligent Management Design

    Real-time monitoring and management of energy storage, release, and distribution.

  • Energy Supply Design

    Advanced battery technology, reliable energy storage solutions, ensuring a stable energy supply to help businesses overcome energy shortages.

  • Modular Design

    Easy to achieve rapid grid connection, convenient expansion, while improving the diversity of battery pack and energy storage PCS system connection.

  • Application Convenience

    The integrated design is highly integrated, making installation and maintenance more convenient.

Special Features
  • 1P240S

    LiFePO4 Cells

  • 7485V

    Low Valtage

  • 215kWh

    Energy Storage

  • ≥6000

    Battery Cycles

  • 5years

    Warranty

Specifications
Technical Specification 100kW/215kWh Integrated Cabinet
System technical parameters
Battery type LFP
Battery capacity 280Ah
Configuration 1P240S
Rated energy 215kWh
Rated voltage 768V
Working voltage range 600Vdc~876Vdc
Maximum charging current 140A
Maximum disharging current 280A
AC section parameters
Rated AC power 100kW
Rated grid voltage 380VAC(±5%)
Rated grid frequency 50/60HZ(±5%)
System efficiency >90%
Overload capacity 1.1times(Long-term)
General parameters
Communication CAN/RS485/Ethernet
EMS Integrated
Cycle life >6000
Cooling method Liquid cooling
Weight 2.7T
Size 1300*1300*2100mm
Protection level IP54/C5H anticorrosive
Working temperature Charge: 0~55℃
Discharge: -20~55℃
Application altitude  ≤2000m
Environmental humidity 0%~95%, no condensation
Floor area 8m²
Noise level ≤75dB
Fire protection system Aerosol automatic fire extinguishing system
Certification UN38.3、MSDS、IEC82619、IEC62477-1、IEC82109、IEC61000-6-3、ROHS、WEE
Grid standard England:G99;Germany:VDE-AR-N 4105;
Spain: NTS 631,UNE 217001 relegation un 217002;RD647;RD413:RD1699;
Italy:CEI 0-21;Hungary:MSZ EN 50438;IEC 62109;EU:EN 50549
