Telecom Base Station Backup Battery

48V Lithium-ion Battery

Frame design, 19" standard cabinet installation, 48V base station, and 240V HVDC system

The 48V rack-mounted Communication Lithium-ion battery is designed specifically for the telecommunications market and can be installed in a 19 - or 21-inch standard cabinet or rack. The line of products combines secure and reliable LFP battery modules with dedicated BMS for high reliability, security and scalability when used in different telecommunications systems, enabling new lithium-ion batteries to be used with older batteries to save costs. We offer two types of configurations to suit the voltage limits of different power supplies.

Telecom Base Station Backup Battery
Telecom Base Station Backup Battery
Telecom Base Station Backup Battery
>
<
Highlights
  • Fast charge & discharge

    10 times faster than lead acid battery

  • Long cycle life

    10 times faster than lead acid battery

  • Wide temperature range

    - 20-55°C

  • Light weighting

    Third of lead acid battery with same capacity

  • Low self-discharge rate

    >≤2% per month

  • High-strength ABS shell

    Laser Welding Rigid tests before shipment

Special Features
  • LiFePO4

    A+ Tier Cells

  • 51.2V

    Voltage

  • 5kWh

    Energy

  • ≥3500

    Battery Cycles

  • 5years

    Warranty

Specifications
Parameters Technical Specifications
Rated capacity (Ah) 100
Rated energy (kWh) 5.12
Nominal voltage (V) 51.2
Cell specifications 3.2V 100Ah
System configuration 1P16S
size (mm) 480*440*222(exeluding hanging ear handle)
Base Station: 5U Size
weight (Kg) 50
Charging Cut-off Voltage (V) 56.4
Discharge Cut-off Voltage (V) 46
Rated Charge current  (A) 50
Rated Discharge current (А) 80
30s Discharge current (А) 100
Working Temperature (℃) Charging: 0-45
Discharging: 10-60
Storage Temperature (℃) 10-45

Note: The temperature condition is 25 ± and 2°C.



Project Cases

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

>
<
Solutions

EV Battery Swapping Solution

Since its establishment, RAJA has been focusing on the continuous development of intelligent products, network integration and big data, cloud computing platform. In different stages of the life cycle of new energy batteries, application management can be carried out in different scenarios to realize resource recovery and cascade utilization, covering the whole life cycle management of batteries.

Learn More >

EV Battery Swapping Solution

Since its establishment, RAJA has been focusing on the continuous development of intelligent products, network integration and big data, cloud computing platform. In different stages of the life cycle of new energy batteries, application management can be carried out in different scenarios to realize resource recovery and cascade utilization, covering the whole life cycle management of batteries.

Learn More >

EV Battery Swapping Solution

Since its establishment, RAJA has been focusing on the continuous development of intelligent products, network integration and big data, cloud computing platform. In different stages of the life cycle of new energy batteries, application management can be carried out in different scenarios to realize resource recovery and cascade utilization, covering the whole life cycle management of batteries.

Learn More >

EV Battery Swapping Solution

Since its establishment, RAJA has been focusing on the continuous development of intelligent products, network integration and big data, cloud computing platform. In different stages of the life cycle of new energy batteries, application management can be carried out in different scenarios to realize resource recovery and cascade utilization, covering the whole life cycle management of batteries.

Learn More >
>
<
