20Ft 3.44MWh liquid cooled container ESS
20Ft standard container ESS-3.44MWh
RAJA cabinet energy storage system series is mainly composed of the energy storage battery, battery management system (BMS), monitoring system, fire protection system, temperature control system, and container auxiliary system. The product is applicable to power plants, power grid, and user side, and can be customized to meet actual requirements. It can be used for 1c or lower charging and discharging scenarios.
More Files
-
Highly integrated design
Integrated in a 20-foot standard container for easy transportation and delivery.
-
Pre-installation design
Greatly reduce the installation workload on the construction site.
-
Safe & reliable
High thermal stability of LFP cell, IP54 for outdoor applications, C5 corrosion protection, 20 years of reliability.
-
Three-stage pressure relief valve design
Battery unit explosionproof valve + battery pack explosion-proof valve + container pressure relief plate.
-
Efficient thermal management
The use of liquid cooling extreme temperature control system, battery cluster internal cell temperature difference ≤2.5℃, life increased by 33%.
-
Intelligent & friendly
Support cell internal resistance real-time detection, multi-dimensional analysis of battery status. Rapid state detection and fault recording, to achieve rapid system fault location and analysis.
-
10P384S
LiFePO4 cells
-
3150kVA
Rated power
-
3.44MWh
Energy storage
-
≥6000
Battery cycles
-
＞90%
System efficiency
|
Technical Specifications |
|
|
Model |
RAJA-GESS-B3-E025 |
| Battery type | LFP |
|
Nos of cells |
10P384S |
| Rated energy | 3.44 MWh |
|
Rated voltage |
1228.8V |
|
Operating voltage |
960~1401.6V |
|
DCVoltage Range [V] |
638-820 |
|
Max. Continuous Charging Rate(C) |
0.5 |
|
Max. Continuous Discharging Rate(C) |
0.5 |
|
Communication Mode |
Ethernet、GPRS、RS485、CAN2.0 |
|
Container Size[W*D*H,mm] |
12192*2896*2438 |
|
Weight[T] |
~30 |
|
Protection level |
IP54 |
|
Fire Protection System |
Yes |
|
Cooling method |
Liquid coooling |
|
Noise Level(dB) |
<65 |
|
Operating Temperature(℃) |
-20 to+60 |
|
Storage Temperature(℃) |
-20 to+60 |
|
Relative Humidity[non-condensing] |
5%-95% |
|
Highest Altitude |
4500m(derating above 3000m) |
