2.56kWh All-in-one Energy Storage

All-in-one series comes with two models, 2.56kWh(FA3000A) and 5.12kWh(FA5000A), both models have been integrated with inverter that is best suited for offgrid solar system. Plug and use type.

To be designed for homes with demand for small and medium power storage.

Product Features

Safe & Endurable

BMS & Inverter have been proven to be the reliable, durable based on over 20years technological hands-on experience.
Effortless Connection

Inverter integrated without hassle of extra wire connection to between the battery and inverter. Plug and use.
For Small Power Storage

2.56kWh & 5.12kWh cater for homes with small or medium-power loads that consume power less than 5KWH at night.
Built-in Inverter

Built in a premium sine wave inverter, combined with a lithium battery module, to provide excellent performance and is suitable for charging from solar panels and powering electrical load applications.
Easy to Set up

Raja all-in-one series household energy storage system is designed with PV interface for off-grid solar systems. Thanks to the compact integrated design, it is very convenient for wall-mounted installation, plug and play.
Smart BMS

Powerful intelligent BMS, anti-overheating, over-charging, over-discharge and other multiple protection design, continue to ensure the stable operation of the battery, improve the battery performance, while extending the battery life.

Special Features

1P8S

LiFePO4 Cells
3.2kW

Inverter
2.56kWh

Energy Storage
≥2000

Battery Cycles
1years

Warranty

Specifications

Technical Specification	FA3000A
Inverter Characteristic
Inverter type	Off-grid
AC rated power/Peak power	3.2kW/6.4kW
Vac input/output voltage	230Vac±5%
PV MPPT range	90V-430V
Maximum PV input current	10A
Maximum charging current	50A
Battery Chracteristic
Rated voltage	51.2V
Rated capacity	100Ah(0.5/25℃)
Rated energy	2.56kWh (0.5/25℃)
Display	LCD/APP
Size	590×680×243mm
Weight	58kg
Protection level	IP40
Working temperature	Charge: 0-55℃
Working temperature	Discharge: -20-60℃
Storage temperature	10-35℃
Inverter Characteristic
UN38.3//MSDS/ICE62619/ICE61000-6-1/IEC60000-6-3730/ROHS/WEEE
