Hybrid Inverter Three-phase 8kWh

8kW Three-phase Hybird Inverter

RAJA 3-phase hybrid inverter supports simultaneous input of photovoltaic, battery, diesel generator, power grid, and load for self-use, peak adjustment and valley compensation, and backup power supply.

It supports parallel connection of multiple machines and is suitable for various applications of energy storage in villas, communication base stations, farms and residential homes.

Hybrid Inverter Three-phase 8kWh
Hybrid Inverter Three-phase 8kWh
Hybrid Inverter Three-phase 8kWh
Hybrid Inverter Three-phase 8kWh
>
<
Product Features
  • Switching

    Automatic battery switching.

  • Options

    Input power source priority can be set by users.

  • Multi-Source

    Support Diesel Generator Input Source.

  • Compatibility

    Compatible with Lead-acid and Lithium-ion Batteries.

  • Expansion

    Parallel available, intelligent BMS management.

  • Protection

    Battery Reverse Connection protection, anti-power control function.

Special Features
  • Luxury Villa

  • Communication Base Station

  • Nomadic Farm

  • Residential Electricity

Specifications
Three Phase Hybrid Inverter
PV Input Parameters
Max Power(kW) 10.4
Max DC Voltage(V) 1000
MPPT Voltage Range(V) 180~850
Single MPPT Max Input Current(A) 12.5
MPPT NOS/ Series & Parallel 2/1
AC Output Parameters
Rated Output Power(kVA) 8.8
Max Output Current(A) 12.7
Grid Voltage Range(V) 400/360~440
Grid Frequency(Hz) 50 /60
Power Factor 0.8advance ~0.8lagging
THDi <3%
Grid Connection Type 3W+N+PE
Battery Parameters
Voltage Range(V) 125~600
Max Charging Voltage(V) 600
Full Load Voltage(V) 210
Max Charge/Discharge Current(A) 40
Battery Type Lithium / Lead Acid
Communication Interface CAN/RS485
EPS Output Parameters
Rated Power(kVA) 8.8
Rated Output Voltage(V) 400
Rated Output Current(A) 12.7
Rated Output Power(Hz) 50 /60
Auto Switch Time(ms) <20
THDu <2%
Overload Ability 110%, 30S/120%, 10S/150%, 0.02S
General Parameters
Charge/Discharge Efficiency 96.6%
Max Efficiency 97.9%
Efficiency for EU 97.2%
MPPT Efficiency 99.5%
Protection Level IP65
Noise(dB) <35
Environmental Temperature Range -25℃~60℃
Cooling Method Natural Cooling
Environmental Humidity Range 0 ~95% (no condensation)
Altitude 2000m (no power loss)
Dimension W*D*H(mm) 530*200*600
Weight(kg) 29
Static Power Consumption(W) <3
Display & Communication
Display LCD
 RS485/Wifi/4G/ CAN/DRM Optional
Compliance
Safety IEC/EN62109-1/-2, IEC/EN62477-1
EMC IEC/EN 61000-6-1, IEC/EN 61000-6-3
Ongrid Europe:EN50549-1,  Germany:VDE4105/0124,UK:G99,South Africa:NRS097-2-1:2017
