High Voltage Stackable Battery System 5kWh

20.48kWh-40.96kWh Stackable

High Voltage Stackable Series comes with two types, single-module 3.07kWh(FD3000A) high voltage lithium battery and single-module 5.12kWh(FD5000C) high voltage lithium battery.

FD5000C can achieve voltage from 102V to 307V for various demands after stacking. Stackable design makes them easily be expanded from single module to multiple modules upon actual needs.

High Voltage Stackable Battery System 5kWh
High Voltage Stackable Battery System 5kWh
>
<
×
Product Features
  • Safe & Endurable

    Self-developed BMS provides the ultmost protection to battery, compatible with major Inverter brands.

  • Effortless Connection

    Stackable design, module connection can be done within minutes.

  • For Ongrid Inverters

    Work with hybrid(on/off grid) inverters that feed the power to states grid.

  • Modular Design

    The battery string, control box, and rack base are modular, saving space and facilitating flexible configuration on demand.

  • Easy to Expand

    Support 3-phase circuit connection. The power of a single module is 5.12kWh, which can be easily expanded through series stacking to meet the power demand from 20kWh to 40kWh.

  • Smart BMS

    Powerful intelligent BMS, anti-overheating, over-charging, over-discharge and other multiple protection design, continue to ensure the stable operation of the battery, improve the battery performance, while extending the battery life.

Special Features
  • 1P16S

    LiFePO4 Cells

  • 51.2V

    High voltage

  • 20.48kWh~40.96kWh

    Battery energy

  • ≥6000

    Cycle life

  • 3years

    Warranty

Specifications
High voltage stackable 5kWh
Single module specification FD5000C
Rated capacity 100Ah
Rated energy 5.12kWh
Nominal voltage 51.2V
Charge cut-off voltage 58.4V
Discharge cut-off voltage 43.2V
Rated charge current 50A
Rated discharge current 100A
Size 600*400*162mm
Weight 44.2kg
Working temperature Charge: 0~55℃
Discharge: -20~60℃
Storage temperature 10~35℃
Stacking specification FD5000C
Num of modules 4 5 6 7 8
Rated energy 20.48kWh 25.60kWh 30.72kWh 35.84kWh 40.96kWh
Battery capacity 100Ah
Rated Voltage 204.8V 256V 307.2V 358.4V 409.6V
Configuration 1P64S 1P80S 1P96S 1P112S 1P128S
Battery type LFP

Cycle life

≥6000
Rated charging current 50A
Rated discharge current 100A
Display LCD
Communication CAN
Working temperature Charge: 0~55℃    Discharge: -20~60℃
Storage temperature 10~35℃
Environmental humidity 0~95%
Application altitude 2000m
Size 520*350*1016mm 520*350*1202mm 520*350*1388mm 520*350*1574mm 520*350*1760mm
Weight 200kg 245kg 290kg 335kg 380kg
Installation Ground stacking
Compliance
UN38.3/MSDS/ICE 62619/ICE 62477/IEC 610000-6-1/IEC 610000-6-3/ROHS/WEEE
Product Details

Project Cases

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

>
<
