Electric Mini Van Battery 307V125Ah

Electric Mini Van Battery

Designed to be "Deep-cycle" that means the battery system can be discharged until almost empty, voltage nominal 307.2V and energy is 38.4kWh.

Electric Mini Van Battery 307V125Ah
>
<
Product Features

  • Safe & Endurable

    Self-developed BMS provides the ultmost protection to battery, compatible with major Inverter brands.

  • Smart BMS

    The battery detection unit is installed in the battery pack, which can accurately and real-time detect the battery voltage, temperature, capacity and other conditions, which can fully improve the safety of the product.

  • 10 Years Design Life

    A-class battery cells, with the protection of BMS, the system can deliver up to 10 years servicelife.

  • Reliable

    Longer lifespan Laser Welding Rigid tests before shipment.

  • Adaptable

     Self-heating function, consistent and efficient at -20 to 50 degrees.

  • Intelligent Monitoring

    Monitor the battery status at any time on the APP, while the LCD window displays real-time data, battery charging, discharge and other data at a glance.

Special Features

  • LiFePO4

    A+ Tier Cells

  • 307.2V

    Voltage

  • 38.4kWh

    Energy

  • ≥3500

    Battery Cycles

  • 5years

    Warranty

Specifications
307V125Ah-EVBattery-LightTruck
SPECIFICATIONS
RatedCapacity 125Ah
RatedEnergy 38.4kWh
NominalVoltage 307.2V
Dimension 1140*924*240mm
Weight approx.295kg
ChargeCut-offVoltage 350V
DischargeCut-offVoltage 240V
RatedChargeCurrent 100A
RatedDischargeCurrent 125A
RatedDischargeCurrentin30S 180A
Communication CAN
PortofCharge&Discharge sameport
ProtectionLevel IP67
WorkingTemperature Charge:0～60℃
Discharge:-30～60℃
StorageTemperature 0~45℃
StateofCharge(SOC)beforeShipment 30%~50%
LifeCycles ≥3500@25℃
PROTECTIONPARAMETERS
SingleCellovercharge ProtectionVoltage 3.7V Canbesetmanually
ProtectionDelay 2.0s Canbesetmanually
SingleCellover-discharge ProtectionVoltage 2.5V Canbesetmanually
ProtectionDelay 2.0s Canbesetmanually
TotalVoltageOvercharge ProtectionVoltage 355V Canbesetmanually
ProtectionDelay 2.0s Canbesetmanually
TotalVoltageOver-discharge ProtectionVoltage 240V Canbesetmanually
ProtectionDelay 2.0s Canbesetmanually
ChargeOver-current ProtectionCurrent 180A Canbesetmanually
ProtectionDelay 2.0s Canbesetmanually
DischargeOver-current ProtectionCurrent 225A Canbesetmanually
ProtectionDelay 2s Canbesetmanually
TemperatureProtection TopChargeTemperature 65℃ Canbesetmanually
LowestChargeTemperature 0℃ Canbesetmanually
TopDischargeTemperature 65℃ Canbesetmanually
LowestDischargeTemperature -10℃ Canbesetmanually
