Low Speed Vehicle Battery 51.2V15Ah

Low Speed Vehicle Battery 51.2V15Ah

Provides power to low speed vehicles like 2/3 wheelers.

Designed to be "Deep-cycle" that means the battery system can be discharged until almost empty, voltage nominal 51.2V and energy is 768Wh.

A+ class LiFePO4(Lithium Iron Phosphate) cells, up to 3000cycles(8-10years). The capacity remains higher than 80% after 2000+cycles, even after 3000+cycles(10-12years), the capacity can still be over 70%.

Battery cells packing process is completely in accordance with the standards of EV Battery production, embracing the laser welding techniques to ensure every cell to be soldered completely, avoiding insufficient or poor soldering.

Low Speed Vehicle Battery 51.2V15Ah
>
<
Product Highlights
  • Safe & Endurable

    Self-developed BMS provides the ultmost protection to battery, compatible with major Inverter brands.

  • Smart BMS

    The battery detection unit is installed in the battery pack, which can accurately and real-time detect the battery voltage, temperature, capacity and other conditions, which can fully improve the safety of the product.

  • 10 Years Design Life

    A-class battery cells, with the protection of BMS, the system can deliver up to 10 years servicelife.

  • Reliable

    Longer lifespan Laser Welding Rigid tests before shipment.

  • Adaptable

     Self-heating function, consistent and efficient at -20 to 50 degrees.

  • Intelligent Monitoring

    Monitor the battery status at any time on the APP, while the LCD window displays real-time data, battery charging, discharge and other data at a glance.

Special Features
  • LiFePO4

    A+ Tier Cells

  • 51.2V

    Voltage

  • 768kWh

    Energy

  • ≥3500

    Battery Cycles

  • 5years

    Warranty

Specifications
51.2V15Ah- EV Battery- Low Speed Vehicles
SPECIFICATIONS
Rated Capacity 15Ah
Rated Energy 768Wh
Nominal Voltage 51.2V
Dimension 173*145*234mm
Weight approx. 7.5kg
Charge Cut-off Voltage 58.4V
Discharge Cut-off Voltage 40V
Rated Charge Current 10A
Rated Discharge Current 15A
Rated Discharge Current in 15S 50A
Communication CAN
Port of Charge & Discharge Work Independently
Protection Level IP65
Working Temperature Charge: 0~45℃
Discharge: -20~60℃
Storage Temperature 10~45℃
State of Charge(SOC) before Shipment 30%~50%
PROTECTION PARAMETERS
Over Charge Single Cell Protection Voltage 3.65V
Total Protection Voltage 58.4V
Measures Output Break
Over Discharge Single Cell Protection Voltage 2.5V
Total Protection Voltage 40V
Measures Output Break
Over Current Charge Protection Current 25A
Discharge Protection Current 55A
Measures Output Break
Temperature Top Discharge Temperature 65℃
Measures Output Break
