Low Speed Vehicle Battery 60V20Ah

Low Speed Vehicle Battery 60V20Ah

Provides power to low speed vehicles like 2/3 wheelers. Designed to be "Deep-cycle" that means the battery system can be discharged until almost empty, voltage nominal 60V and energy is 1.28kWh.

Low Speed Vehicle Battery 60V20Ah
>
<
Product Features
  • Safe & Endurable

    Self-developed BMS provides the ultmost protection to battery, compatible with major Inverter brands.

  • Smart BMS

    The battery detection unit is installed in the battery pack, which can accurately and real-time detect the battery voltage, temperature, capacity and other conditions, which can fully improve the safety of the product.

  • 10 Years Design Life

    A-class battery cells, with the protection of BMS, the system can deliver up to 10 years servicelife.

  • Reliable

    Longer lifespan Laser Welding Rigid tests before shipment.

  • Adaptable

     Self-heating function, consistent and efficient at -20 to 50 degrees.

  • Intelligent Monitoring

    Monitor the battery status at any time on the APP, while the LCD window displays real-time data, battery charging, discharge and other data at a glance.

Special Features
  • LiFePO4

    A+ Tier Cells

  • 64V

    Voltage

  • 1.28kWh

    Energy

  • ≥3500

    Battery Cycles

  • 5years

    Warranty

Specifications
60V20Ah- EV Battery- Low Speed Vehicles
SPECIFICATIONS
Rated Capacity 20Ah
Rated Energy 1.28kWh
Nominal Voltage 64V
Dimension 280*170*140mm
Weight approx. 11kg
Charge Cut-off Voltage 73V
Discharge Cut-off Voltage 50V
Rated Charge Current 10A
Rated Discharge Current 30A
Rated Discharge Current in 30S 50A
Communication CAN/RS485
Port of Charge & Discharge Same Port
Protection Level IP65
Working Temperature Charge: 0~45℃
Discharge: -20~60℃
Storage Temperature 10~45℃
State of Charge(SOC) before Shipment 30%~50%
PROTECTION PARAMETERS
Single Cell Over Charge Protection Voltage 3.68V Can be set manually
Restore Voltage 3.60V Can be set manually
Protection Delay 5.0s Can be set manually
Restore Conditions
1.Auto restore once the voltage drops to the value.
2.Detecting there is a valid discharging current from battery.
Single Cell Over Discharge Protection Voltage 2.5V Can be set manually
Restore Voltage 2.9V Can be set manually
Protection Delay 5.0s Can be set manually
Restore Conditions 1.Auto restore once the voltage rises to the value.
2.Detecting there is a valid charging current from battery.
Total Voltage Over Charge Protection Voltage 73V Can be set manually
Restore Voltage 70V Can be set manually
Protection Delay 5.0s Can be set manually
Restore Conditions 1.Auto restore once the total voltage drops to the value.
2.Detecting there is a valid discharging current from battery.
Total Voltage Over Discharge Protection Voltage 50V Can be set manually
Restore Voltage 58V Can be set manually
Protection Delay 5.0s Can be set manually
Restore Conditions 1.Auto restore once the voltage rises to the value.
2.Detecting there is a valid charging current from battery.
Charge Over Current Protection Current 22A Can be set manually
Protection Delay 5.0s Can be set manually
Restore Conditions 1.Auto restore and re-detect every 2minutes, stops after 10times repetition.
2.Detecting there is a valid discharge current.
Discharge Over Current Protection Current 48A Can be set manually
Protection Delay 15s Can be set manually
Restore Conditions 1.Auto restore and re-detect every 2minutes, stops after 10times repetition.
2.Detecting there is a valid charge current.
Temperature Top Charge Temperature 65℃ Can be set manually
Lowest Charge Temperature 0℃  Can be set manually
Top Discharge Temperature 65℃ Can be set manually
Lowest Discharge Temperature -10℃ Can be set manually
