12.8V Lead Acid replaced by LiFePO4

LiFePO4 Battery 12.8V replacing Lead Acid battery.

For 2 or 3 wheels or other low speed veicles.

Designed to be "Deep-cycle" that means the battery system can be discharged until almost empty, voltage nominal 12.8V and capacity range from 50Ah to 300Ah.

12.8V Lead Acid replaced by LiFePO4
>
<
Product Features
  • Safe & Endurable

    Self-developed BMS provides the ultmost protection to battery, compatible with major Inverter brands.

  • Smart BMS

    The battery detection unit is installed in the battery pack, which can accurately and real-time detect the battery voltage, temperature, capacity and other conditions, which can fully improve the safety of the product.

  • 10 Years Design Life

    A-class battery cells, with the protection of BMS, the system can deliver up to 10 years servicelife.

  • Reliable

    Longer lifespan Laser Welding Rigid tests before shipment.

  • Adaptable

     Self-heating function, consistent and efficient at -20 to 50 degrees.

  • Intelligent Monitoring

    Monitor the battery status at any time on the APP, while the LCD window displays real-time data, battery charging, discharge and other data at a glance.

Special Features
  • LiFePO4

    A+ Tier Cells

  • 12.8V

    Voltage

  • 50Ah-300Ah

    Capacity

  • ≥3500

    Battery Cycles

  • 5years

    Warranty

Specifications

Technical Specifications

NO.

Rated

voltage

Rated

capacity(Ah)

Size(mm)

Charging

current(A)

Discharging

current(A)

Operating voltage

range(V)

Operation

temperature range(℃)

Weight(kg)

Terminal

1

12.8V

50Ah

195*165*168

25

50









Charging upper

limitvotage 146V

Lower discharge

limityoltage 10V









Charging temperature range:0~45°℃

Discharge temperature range20~55℃

7.7

M6

2

12.8V

100Ah

306*168*210

50

100

12.7

M8

3

12.8V

120Ah

330*173*235

50

100

15.4

M8

4

12.8V

136Ah

405*173*230

50

100

17.4

M8

5

12.8V

150Ah

522*240*218

50

100

19.2

M8

6

12.8V

200Ah

522*240*218

50

100

24

M8

7

12.8V

250Ah

522*240*218

50

100

32

M8

8

12.8V

300Ah

522*240*218

50

150

38.4

M8

Project Cases

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

Residential ESS

Austrilia 20.58kWp

Inverter 10kW Battery FD5000C-20kWh

>
<
Solutions

Residential ESS

Thanks to its combination with photovoltaic systems, YAJUN House ESS makes green energy available 24/7, providing a clean electricity solution for your own solar-powered home. If you are looking for a home solution that is safe, reliable and easy to install, the YAJUN is ideal for homeowners using solar power. Enjoy your unparalleled green energy experience, optimal solar energy use, reduced electricity bills and much more.

Learn More >

C&I ESS

YAJUN provides commercial and industrial energy solutions for EPCs, developers, and owner-operators to utilize the roof resources. With unrivalled technical expertise and optimized design, GoodWe can comprehensively drive new revenue streams and project value for our users with high-current PV module compatibility.

Learn More >

Balcony Solar System

The balcony solar system is specially designed for small Spaces such as balconies or terraces micro-photovoltaic power stations. Combined with an intelligent management platform, the solution can generate clean, renewable energy to power a home or apartment. it is an ideal choice for owners who do not want to occupy outdoor space or lack outdoor installation space.

Learn More >

PV power station integrated solution

PV power station integrated solution integrates solar, storage, and charging station system into a single solution, which not only meets the challenges related to limited land and electrical capacity resources but also achieves a balance between local energy production and electrical load through energy storage and optimal configuration.

Learn More >
>
<
