Light Truck Battery 512V160A

Light Truck Battery 512V160A

Designed to be "Deep-cycle" that means the battery system can be discharged until almost empty, voltage nominal 512V and energy is 81.9kWh.

Light Truck Battery 512V160A
Light Truck Battery 512V160A
Light Truck Battery 512V160A
>
<
Product Features

  • Safe & Endurable

    Self-developed BMS provides the ultmost protection to battery, compatible with major Inverter brands.

  • Smart BMS

    The battery detection unit is installed in the battery pack, which can accurately and real-time detect the battery voltage, temperature, capacity and other conditions, which can fully improve the safety of the product.

  • 10 Years Design Life

    A-class battery cells, with the protection of BMS, the system can deliver up to 10 years servicelife.

  • Reliable

    Longer lifespan Laser Welding Rigid tests before shipment.

  • Adaptable

     Self-heating function, consistent and efficient at -20 to 50 degrees.

  • Intelligent Monitoring

    Monitor the battery status at any time on the APP, while the LCD window displays real-time data, battery charging, discharge and other data at a glance.

Special Features

  • LiFePO4

    A+ Tier Cells

  • 512V

    Voltage

  • 81.92kWh

    Energy

  • ≥3500

    Battery Cycles

  • 5years

    Warranty

Specifications
512V160Ah- EV Battery- Light Truck
SPECIFICATIONS
Rated Capacity 160Ah
Rated Energy 81.92kWh
Nominal Voltage 512V
Dimension 1520*496*180mm
Weight approx. 640kg
Charge Cut-off Voltage 584V
Discharge Cut-off Voltage 400V
Rated Charge Current 100A
Rated Discharge Current 160A
Rated Discharge Current in 30S 240A
Communication CAN
Port of Charge & Discharge same port
Protection Level IP67
Working Temperature Charge: 0～60℃
Discharge: -30～60℃
Storage Temperature 0~45℃
State of Charge(SOC) before Shipment 30%~50%
Life Cycles ≥3500 @25℃
PROTECTION PARAMETERS
Single Cell overcharge Protection Voltage 3.7V Can be set manually
Protection Delay 2.0s Can be set manually
Single Cell over-discharge Protection Voltage 2.5V Can be set manually
Protection Delay 2.0s Can be set manually
Total Voltage Overcharge Protection Voltage 592V Can be set manually
Protection Delay 2.0s Can be set manually
Total Voltage Over-discharge Protection Voltage 400V Can be set manually
Protection Delay 2.0s Can be set manually
Charge Over-current Protection Current 160A Can be set manually
Protection Delay 2.0s Can be set manually
Discharge Over-current
Temperature Protection 		Protection Current 288A Can be set manually
Protection Delay 2s Can be set manually
Top Charge Temperature 65℃ Can be set manually
Lowest Charge Temperature 0℃  Can be set manually
Top Discharge Temperature 65℃ Can be set manually
Lowest Discharge Temperature -10℃ Can be set manually
