C&I liquid-cooled outdoor energy storage cabinet

Energy Storage is 215~344kWh

Our outdoor energy storage cabinet is an intelligent integrated management system that provides reliable and efficient energy storage for outdoor applications. With its scalable capabilities, RAJA's battery system can meet project requirements of varying scale and is suitable for various environmental conditions, making it an ideal solution for grid ancillary services and C&I applications while ensuring reliability and safety.

C&I liquid-cooled outdoor energy storage cabinet
>
<
Product Features
  • Safe & Endurable

    Robust electrical systems and fire-resistant materials for high-temperature and high-pressure tolerance.

  • High Protection Level

    Our outdoor cabinet is IP66 constructed in a environmentally controlled liquid cooled cabinet including fire suppression.

  • For C&I Power Storage

    Max. installed capacity up to 344kWh per cabinet.

  • Intelligent Management

    Built-in battery management system, HVAC, and automatic fire suppression system.

  • Simplified Design

    Quick installation, easy maintenance, regular automatic fault diagnostics with EMS.

  • Cyclic Lifespan Design

    Long-lasting battery systems capable of thousands of charge-discharge cycles.

Special Features
  • 1P384S

    LiFePO4 Cells

  • 1228.8V

    Low Voltage

  • 344kWh

    Energy Storage

  • ≥6000

    Battery Cycles

  • 5years

    Warranty

Specifications
Liquid-cooled Outdoor Energy Storage Cabinet Specification
Nos of Moudules 5 6 7 8
Configuration 1P240S 1P288S 1P288S 1P384S
Rated Energy 215kWh 215kWh 215kWh 344kWh
Rated Voltage 768V 768V 1075.2V 1075.2V
Operation Voltage 600~876Vda 600~876Vda 600~876Vda 600~876Vda
Max Charging Current 140Ah
Max Disharging Current 280Ah
System efficiency >90%
General Parameters
Communication CAN/RS485/Ethernet
 EMS Integrated
Life Cycle >6000 times
Product Dimension 1300mm*1300mm*2300mm
Weight 2300~3200kg
Altitude ≤2000
Humidity 0~95%, non-Condensing
Protection IP66/C5H
Land area 5㎡
Fire protection Cluster Aerosol
Noise ≤75dB
Working Temp Charging:0~55℃
Discharging:-20~55℃
Certification UN38.8,MSDS,IEC62619,IEC62477-1,IEC6100-6-1,IEC62109,IEC6100-6- 3,ROHS,WEEE
