Sanitation Vehicle Battery 588V173Ah

Sanitation Vehicle Battery 588V173A

Designed to be "Deep-cycle" that means the battery system can be discharged until almost empty, voltage nominal 588V and energy is 101.8kWh.

Product Features

Safe & Endurable

Self-developed BMS provides the ultmost protection to battery, compatible with major Inverter brands.
Smart BMS

The battery detection unit is installed in the battery pack, which can accurately and real-time detect the battery voltage, temperature, capacity and other conditions, which can fully improve the safety of the product.
10 Years Design Life

A-class battery cells, with the protection of BMS, the system can deliver up to 10 years servicelife.
Reliable

Longer lifespan Laser Welding Rigid tests before shipment.
Adaptable

Self-heating function, consistent and efficient at -20 to 50 degrees.
Intelligent Monitoring

Monitor the battery status at any time on the APP, while the LCD window displays real-time data, battery charging, discharge and other data at a glance.

Special Features

LiFePO4

A+ Tier Cells
588V

Voltage
101.8kWh

Energy
≥3500

Battery Cycles
5years

Warranty

Specifications

588V173Ah- EV Battery- Sanitation Vehicle
SPECIFICATIONS
Rated Capacity		173Ah
Rated Energy		101.8kWh
Nominal Voltage		588.8V
Dimension		1245456242mm
Weight		approx. 732kg
Charge Cut-off Voltage		671.6V
Discharge Cut-off Voltage		460V
Rated Charge Current		150A
Rated Discharge Current		170A
Rated Discharge Current in 30S		255A
Communication		CAN
Port of Charge & Discharge		same port
Protection Level		IP67
Working Temperature		Charge: 0～60℃
		Discharge: -30～60℃
Storage Temperature		0~45℃
State of Charge(SOC) before Shipment		30%~50%
Life Cycles		≥3500 @25℃
PROTECTION PARAMETERS
Single Cell overcharge	Protection Voltage	3.7V	Can be set manually
	Protection Delay	2.0s	Can be set manually
Single Cell over-discharge	Protection Voltage	2.5V	Can be set manually
	Protection Delay	2.0s	Can be set manually
Total Voltage Overcharge	Protection Voltage	680V	Can be set manually
	Protection Delay	2.0s	Can be set manually
Total Voltage Over-discharge	Protection Voltage	460V	Can be set manually
	Protection Delay	2.0s	Can be set manually
Charge Over-current	Protection Current	150A	Can be set manually
	Protection Delay	2.0s	Can be set manually
Discharge Over-current	Protection Current	310A	Can be set manually
	Protection Delay	2s	Can be set manually
Temperature Protection	Top Charge Temperature	65℃	Can be set manually
	Lowest Charge Temperature	0℃	Can be set manually
	Top Discharge Temperature	65℃	Can be set manually
	Lowest Discharge Temperature	-10℃	Can be set manually
